Electric generators are the opposite of electric motors, but they work on the same concept. Whereby an electric motor uses an electric current to create a magnetic field, a generator uses a magnetic field to induce an electric current. If you read our article on electric motors, then this should sound very familiar. The process is only reversed.
The current that is produced flows through a conductor which is usually a wire, but it can also be a metal plate. The output of the current is then used to power anything from a small device (e.g. a lamp or computer) to an entire town or city.
What They are Used For
Generators are used to create electricity which then powers homes and businesses. They can be powered by either an electromagnet or a permanent magnet. The type of generator you use will determine how much electricity you can generate.
They are often used to provide backup power in case of a power outage, and they are also used in many portable applications such as camping and RVing. Just about all emergency facilities have backup power, such as hospitals.
In some cases, generators can also be used to supplement the main power source, providing additional power during high-demand periods.
The most common power sources are fuels such as coal, natural gas, or oil.
How Does an Electric Generator Create Energy?
When the generator is turned on, its moving parts create a magnetic field, producing an electric current. (Remember with electric motors, an electric current is produced that provides a magnetic field. This is the opposite of what generators do.) The current flows through wires to an external circuit, where it can be used to power electric devices. In this way, an electric generator converts mechanical energy into electrical energy.
What are the different types of electric generators available on the market today?
The most common type uses a combustion engine to generate electricity. These engines can be powered by gasoline, diesel, natural gas, or propane.
Another type is the steam turbine, which uses steam to power a turbine that generates electricity. Steam turbines can be powered by coal, nuclear reactors, or solar thermal power plants.
The third type of generator is the hydroelectric generator, which uses water to power a turbine that generates electricity. Hydroelectric generators can be powered by waterfalls, dams, or river currents. The Niagara Project is a perfect example of the delivery of electricity via hydroelectric generators.
The fourth type of generator is the wind turbine, which uses wind to power a turbine that generates electricity, but there must be enough wind for the proper amount of electricity to be produced.
Wind turbines can be used in both onshore and offshore locations.
How Can You Choose the Right Electric Generator for Your Needs and Budget?
With so many different brands, models, and features to choose from, it’s hard to know where to start. However, by considering a few factors, you can narrow down your options and find the perfect generator for your needs and budget.
First, decide what type of generator you need. For example, if you only need power for occasional use, such as during a power outage, a portable generator may be sufficient.
However, if you need a constant supply of electricity, such as for a construction site or an RV, a stationary generator would be a better choice.
Next, consider how much power you will need. For most applications, a small generator that produces around 2,000 watts will suffice.
However, if you need to run large appliances or multiple devices at once, you’ll need a more powerful model. Finally, compare prices to find the best value for your money. Be sure to factor in the cost of fuel and maintenance when making your decision. By considering these factors, you can find the perfect electric generator for your needs and budget.
Important Safety Tips
First, always read the manufacturer’s instructions carefully before operating the generator. This will help you to understand how the generator works and what safety measures need to be taken.
Next, make sure that the generator is properly grounded before use. This will help to prevent electrical shock. Finally, never operate the generator near flammable materials or in enclosed spaces, as this can create a fire hazard.
By following these simple safety tips, you can help to ensure that your experience with an electric generator is safe and enjoyable.
When an electric current runs through a wire, a magnetic field is produced and when there is a magnetic field, metallic elements become attracted to it. This is the concept behind the workings of an electric motor.
If we can maintain these elements to move towards the magnetic field and away from it at an ongoing, continuous rate, we can have a device that is constantly spinning.
If we attach something to the part of the device that is constantly spinning, such as a glass plate in the microwave, we have harnessed the power of converting electrical energy into mechanical energy, or more specifically, we have created an electric motor.
What Devices Use Electric Motors?
When you use an electric razor, toothbrush, fan, or vacuum cleaner, you are using an electric motor. Let’s through the inner workings of your car also. That’s probably no surprise, but how about this: washing machines, refrigerators, microwaves, your computer, and even your smartphone!
Confused? Don’t be. Something is needed to operate the refrigerator’s compressor. If there is a mechanical hard drive in your computer, then there is a small motor that turns the disk. And microwaves? Well, something must be spinning that glass plate around, right?
And your electric cars (if you have one). They have motors, which are used to spin the tires as you drive, among other things.
The bottom line is you probably go about your day using some device that uses an electric motor. So now that we know how our lifestyles are affected by these devices, let’s delve into how these motors work.
The Working of an Electric Motor
First, let us focus on the magnetic field that causes the components within the motor to constantly spin.
How is the magnetic field created? Our article on magnetic fields explains this, but in a nutshell, if we connect a wire to a battery, the electrons of each of the atoms will move toward the positive pole of the battery. If we wrap the wire around a metal rod, the magnetic field intensifies.
The Initial Stage
The motor is designed so that the magnetic poles of a rod, called a rotor are always facing the same polarity of a stationary magnet, called a stator, causing the rotor to spin around.
For example, when electricity is turned on, the polarity of one side of the rotor, let’s say the north side is initially facing the north side of the stator, so there will be that repelling effect, causing the rotor to spin in the other direction.
The Next Stage
Well, that initial stage works just as it should because like poles repel each other, but that’s it. Then it stops, so for the rotor to keep spinning, there has to be a mechanism that will cause the poles to reverse continuously.
That is the job of the commutator. This entity keeps reversing the path of the electrons so that the poles are always repelling one another and consequently, keeps the rotor spinning.
Key Parts of an Electric Motor
Let’s review the parts of the motor:
Stator – The stationary part of the motor that creates the magnetic field that causes the rotor to spin. The stator is found in between two pieces of copper that conduct electricity.
Rotor – The rotating part of the motor that is placed within the magnetic field.
Shaft – The shaft of the motor connects the rotor to the stator and is used to power the equipment or machinery.
Commutator – The device that reverses the polarity of the rotor. Like reversing a battery at every spin so that the electrons change course.
Fan – The fan is used to create air flow and increase the efficiency of a motor.
Electric motors are all around us. They are a safe, efficient, and reliable way to power machinery and equipment. They are available in a range of sizes, voltages, and designs and can be powered by a wide range of energy sources, including fossil fuels and renewable energy sources like solar or wind.
Let’s use iron for example. Touch it with another piece of iron and what happens? Nothing! Now take a bare wire, copper preferred. Wrap the copper wire around one of the pieces of iron and what happens? Still nothing!
Now grab both ends of the copper wire and connect it to a battery. What happens? Still nothing – at least nothing noticeable that the naked eye can see!
What is happening when the wires connect to the battery (called a circuit) is that the electrons were random before the circuit was completed and they straightened out, like a row of marching soldiers after the circuit is complete.
These marching electrons will point and move towards the pole ( polarity) of the battery it is connected to. Now let’s get a little more technically correct and call these marching electrons an electric current, and as these electrons (current) are moving through the wire, a magnetic field is produced.
When There is Electric Current, There is a Magnetic Field
But Just What is This Magnetic Field?
If we pick up the other piece of iron (which does not have the copper wire around it) and place it near the iron piece that has the wire wrapped (and thus the electric current), that isolated piece of iron suddenly moves toward the electrified one.
The reason why the iron pieces attract each other is that the iron piece with the copper wire wrapped around it (called a coil) becomes magnetic. And so, we have just created an electromagnet!
For the video below, you might want to put your thinking caps on as it explains pretty well how electromagnetic forces are derived (hint: when electrons move through a wire). We suggest those that who are in school and/or have an absorption for learning continue to this video.
For those that would like to bypass such items as Maxwell’s equations and just want a cheat sheet of what is the criteria for an electromagnetic field, see our summary below.
How Electromagnets are Made
An electromagnet can be made out of any type of metal, but iron and nickel are the ones most often used. Nickel magnets are stronger than iron magnets, but iron is cheaper.
Iron is found in most scrap yards, or you can buy it from a hardware store. The first step in making an electromagnet is to create a wire that is wrapped with a coil of metal several times. This is known as an electromagnet coil. The coil has to be wrapped around a core, which is made out of a non-magnetic material.
The Magnetic Field
The electromagnetic field is the region of energy surrounding a magnet. The magnetic field is perpendicular to the path where the electrons flow.
Why are Electromagnets Important?
Electromagnets are important because they can be used to power items and devices that are used by us every day. Motors and generators are just two examples. They are also used in toys, as a way of moving things around in a car or even to move things in a factory.
They are also useful because they’re easily controllable. If you want to turn the electromagnet off, you simply turn off the electric current running through it. If you want to turn it back on, you can simply turn it back on again.
Types of Magnets
There are two types: temporary and permanent. Temporary magnets are only magnetic while electricity is running through them. Permanent magnets remain magnetic no matter what happens. This is because these magnets are not electrified. An example is the ones stuck to your fridge or another metal surface.
Magnetism is created when electrons are in movement. In a practical sense, this means that if you connect a wire to a battery (power source), electrons will move from the negative pole to the positive pole of the battery.
When this happens, a force is created in addition to the electrical force, which is the magnetic force. This magnetic force ‘pushes’ perpendicular to electrical force (current), so any metal that has magnetic properties will be attracted to this force and move towards it accordingly.
The magnetic force can be strengthened by any of the following criteria.
Take the straight wire and curl it around the medium, usually an iron bar. The result is called a coil.
Wiring the coil more will cause the magnetic field to strengthen.
Increasing the current; that is, increasing the speed at which the electrons travel through the coiled wire will also strengthen the magnetic field.
The practical applications of electromagnets are the ability to cause an entity to move because of this force, such as what happens inside a motor.
If you watched Star Trek, in one episode, the Nomad, the robot that referred to humans as carbon-based lifeforms, and for good reason. Because that’s what we are!
Virtually every organic compound on Earth contains carbon. Life as we know it would not exist without carbon. That’s because it has a unique ability to bond with itself and other elements fairly easily, due to its need to find more electrons to bond with.
Because the carbon atom has a natural desire to fulfill its outer shell with eight electrons or saying it another way, it needs to fill up its outer energy level, it will constantly look to bond with other atoms to obtain four more electrons. Once bonded, the atom’s outer shell is fully stable. Carbon atoms can form bonds with other carbon atoms, but they can also form bonds with almost all other elements.
Carbon can exist in multiple different forms known as allotropes: graphite, diamond, and others. It’s also a non-metal, but one of the most important elements on earth. Carbon atoms have many uses, from making steel to fueling cars.
This article explores almost everything you wanted to know about carbon atoms and their various forms.
Types (Allotropes) of Carbon Molecules
Graphite is an allotrope of carbon. It’s a black and soft mineral that is commonly found in nature in the form of pencils. Although graphite is often treated as a mineral, it’s more commonly considered a form of carbon. Graphite is very soft and can be easily compressed into a very thin sheet.
Graphite is made of layered sheets of carbon atoms that form stacks known as graphene. Each layer is made of carbon atoms arranged in a hexagonal pattern with strong covalent bonds. These layers are held together by weak intermolecular forces that are easily broken by heat. That’s why pencils can be erased by rubbing graphite and paper together!
The diamond is another allotrope of carbon. The only difference between the two is that diamonds are made of carbon atoms arranged in a cubic pattern. This makes diamonds a hard and rigid substance.
Diamonds are also made of graphene sheets that are held together by strong covalent bonds. These properties make this mineral extremely valuable, but they’re also highly limited in supply. That’s why they’re one of the most expensive materials on earth.
It’s estimated that only 0.1% of the carbon that enters the earth’s surface is converted into a diamond. This is large because diamonds are formed at very high pressures beneath the earth.
The covalent bonds that can form carbon can result in many different types of molecules. Carbon can form thousands of bonds with other elements. This is why carbon has so many uses in the world.
Fullerenes are carbon molecules that are composed of many rings of carbon. They were accidentally discovered in 1985 by two scientists who were studying carbon soot. The discovery was so exciting that the scientists won a Nobel Prize for their discovery!
C 60 – the most common carbon molecule – has 60 carbon atoms arranged in a spherical pattern. This sphere can be thought of as a football because the name “fullerene” comes from two English words: football and carbon.
C 60 is known as a buckyball and can be used as a tool for scientists. Yes, that’s what it’s called. Buckyballs are carbon atoms that are bonded to three other carbon atoms. Scientists can use buckyballs to study the structure of other molecules.
Why is There So Much Carbon in the World?
Carbon is the fourth most abundant element in the universe. Carbon is created in the interiors of stars and then released into the universe when those stars expire. It is present in the earth’s crust in the form of minerals and organic compounds. C 60, the largest buckyball, is only possible at a pressure of 100 gigapascals– the type of pressure that’s found inside giant planets. (A pascal is a unit of pressure. Gigapasclal is that unit of pressure x 1 billion).
Diatomic carbon is the simplest form of carbon. It contains two carbon atoms with one double bond between the atoms. A double bond is where an atom shares its valence electrons with two other atoms, in contrast to a covalent bond created by lighting and oxygen in the air, but it is usually destroyed by other compounds in the atmosphere.
This is important because diatomic carbon is a greenhouse gas. Carbon atoms are released into the atmosphere when plants are burned. These atoms are then oxidized by the other compounds in the air to create more diatomic carbon. Diatomic carbon is one of the most important greenhouse gases in the atmosphere. This is precisely why it was released in the first place!
Carbon is the element that forms the molecules for all known forms of life on earth. It’s the only element that can form molecules with a ratio of electrons to protons that’s necessary for biology.
Carbon is not a metal. Metals are largely defined by their electrical conductivity. Carbon is a non-metal and does not conduct an electrical current.
Carbon is also very common in the universe and can form multiple different types of bonds with other elements, so when Noman called humans carbon-based life forms, because of its abundance in the universe, maybe he met other carbon life forms in the galaxy we just don’t know about yet!
Elon Musk has always been known for his eccentric ideas and they are often so far-reaching and innovative that people don’t believe he’ll follow through on them—at least not in the way he does.
When Elon Musk announced Starlink, it was just more of the same. It sounded like another quirky idea, but this time with a twist. Some people even dismissed it as a PR stunt, and others thought there was no way it could succeed given the current limitations of space technology.
Now that we know more about Starlink and its development, it seems they were all wrong…again. In this article, we’ll discuss everything you need to know about Elon Musk’s Starlink project, how it became a reality, and what it means for space exploration moving forward.
What is Starlink?
Starlink refers to the development of thousands of satellites that are being put into low-Earth orbit as a way to provide internet and communications services across the globe.
This system will be made up of small satellites that will be used to bypass internet issues and other problems that plague both developed and developing countries. The project was first announced in 2016 and, since then, SpaceX has been creating what it calls “the most sophisticated and largest new commercial satellite constellation in history.”
As of 2019, the company has created over 2,000 satellites, with plans to launch 16,000 more in the coming years. The network will be made up of 80 satellites in low Earth orbit, 12,000 satellites in mid-Earth orbit, and 1,800 satellites in geostationary orbit.
The low-Earth orbit satellites will help to provide internet access to remote areas while the mid-Earth satellites will deliver high-speed broadband to urban areas. The geostationary satellites will help to bridge the two networks together.
How Does Starlink Work?
Planning and implementing the Starlink network started in 2016, with the first test satellites launched in 2017. However, a Falcon 9 rocketexplosion at Cape Canaveral put that mission on hold, causing delays to the development of Starlink.
A second launch was scheduled for February 2018, but once again, the mission was put on hold due to inclement weather. The third launch occurred in March 2019, and the rest of the satellites were sent out at regular intervals to complete the network.
Once the network is fully operational, it will be capable of providing internet access to billions of people across the globe.
Why is Starlink Important?
The internet has become a fundamental part of modern life. It is used for everything from staying in touch with friends and family to researching information, finding new hobbies, managing finances, and even procuring employment, not to mention the vast array of political aspects.
If you don’t have internet access, you are essentially cut off from the world, but this is a reality, particularly in the developing world. In places like Africa, Southeast Asia, and South America, many don’t have Internet access. That’s about two-thirds of the world’s population. Unfortunately, this isn’t a problem that can be fixed by simply installing more internet cables. The issue is that there aren’t enough satellites in orbit to provide the coverage needed.
The Problems With the Current System
Communications satellites are designed to orbit at 22369.37 miles above the surface of the Earth, with the International Space Station orbiting at just 248.5 miles above the planet’s surface.
This means that the satellites are out of reach for most people on the ground. Therefore, if someone wants to use a satellite for anything, they need to be connected to a nearby ground station.
There are around 1,800 ground stations currently in operation around the world, but they can’t cover the entire planet. As a result, there are large parts of Africa and South America that don’t have any access to satellites. Even within these areas, coverage is patchy at best.
If you look at a map of satellite coverage in South America, you’ll notice that many places are completely blacked out. This is because there needs to be a clear line of sight between the ground station and the satellite. If a mountain or a building gets in the way, it will completely block the signal. So even if you have a satellite available, it may not be able to provide you with a decent internet connection.
Will People Use It?
It is estimated that SpaceX will have to deal with around 700,000 pieces of space debris when they finally launch all the satellites. But despite this, the company has already sold $1 billion in services to two unnamed customers and is expected to launch thousands of satellites in the coming years.
This is a good sign, particularly since the two customers have remained anonymous until now. While it is impossible to know for sure if people will use the network once it is launched, we can take a look at similar projects in the past to get an idea of the potential for success. For example, Inmarsat, a British satellite telecommunications company, launched a network of satellites in the late ’80s. At the time, the idea of being able to communicate with each other from the middle of the ocean seemed like science fiction. However, the system was so successful that it has been used ever since. The company has over 19 million subscribers and a market capitalization of $14 billion. It has become so successful that it is now “a world-leading provider of global mobile services.”
Starlink is a huge project that will see thousands of satellites put into low-Earth orbit as a way to provide internet and communications services across the globe. Elon Musk introduced the project in 2016 and since then his company has been developing what they call “the most sophisticated and largest new commercial satellite constellation in history.” There are still challenges that need to be overcome, particularly in terms of dealing with space debris. But if everything goes to plan, this will be the start of a new era in the way we access the internet.
Walk down any city construction site and you’re bound to see a network of steel beams and columns rising from the ground. Why are they using steel? Because steel is strong, durable, and easy to work with. It is the iron alloy of choice for building construction.
If you’re wondering how steel is manufactured, wonder no more! In this blog post, we’ll explain the process from start to finish.
History of Steel
The emergence of steel can be traced back to the Iron Age when it is used to make swords. History experts say that the original creators of steel were the Hittites, a middle-eastern civilization that existed during the Bronze Age and later into the Iron age, between 1400 and 1200 B.C. in what is now Syria and Turkey. They learned that by heating iron with carbon, a stronger metallic substance could be made.
Historians are not exactly sure what happened to the Hittites, but the consensus is that they most likely morphed into the Neo-Assyrian Empire (912 to 612 BC).
It has also been discovered that China had first worked with steel around 403–221 BC. and the Han dynasty (202 BBC—AD220) melted wrought iron with cast iron, producing a steel composite.
Modern Day Uses
With the advent of the railroad construction boom in the 19th century and its ongoing requirement for metal to make the tracks, a supply issue was materializing. The process was slow and tedious due since there wasn’t any automatic process to fill the need.
Enter the Steel Mill
Steel mills provided the raw materials for many of the world’s most important products. Since the first mill opened in the early 1800s, they were constantly improved and adapted to meet the needs of the times.
These manufacturing plants have helped build skyscrapers, bridges, and countless other structures. They have also been instrumental in the development of new technologies, solving railway construction issues to assembly lines for other products.
There was no time more profitable for the steel mill than during the industrial revolution which began in the nineteenth century and up to the mid-twentieth century.
And there wasn’t a company more notable to achieve the country’s manufacturing demand than Bethlehem Steel, which provided the product for 125 years starting in 1887.
How Steel is Made
Steel does not grow out of thin air. It begins with the mining of iron ore, which then has to be combined with the element carbon via a blast furnace. Let’s get ma more involved in understanding how this process works.
Mining the Iron Mineral
It all begins with the mining of ironore.An ore represents a mineral from here a valuable asset can be extracted.
Once it is taken out from the quarry, the ore is melted and purified (removing impurities from the ore and leaving only the metal). This is done in a blast furnace.
Carbon is an element in the Periodic Table that has an atomic number of six, with four electrons in its outer shell and two electrons in its inner shell.
Atoms that have less than eight electrons in their outer shell, (called the valence shell) tend to look for other atoms to bond with so that their outer shells can stabilize the atom by balancing the shell to eight electrons. This is based on the Octet Rule.
Iron has eight electrons in its valence shell, so if you bond the carbon atom that has six valence electrons with the iron atom, you have a molecule of two different atoms which forms steel.
It is essential to ensure that the correct amount of carbon is used with iron, approximately 0.04% so that the resultant product is that of steel.
If the wrong amount of carbon is mixed with iron, a different product will be produced such as cast iron or wrought iron – both of these are not efficient to render steel.
When is Carbon Added to Iron?
For steel, the combination of the two elements is done while the iron metal is liquid hot, which then alters the iron’s properties to change to that of steel.
Steel subsequently becomes an alloy (a metal made by combining two or more metallic elements) of iron and carbon. This causes a distortion of the crystalline lattice structure of iron and subsequently enhances the metal’s strength; specifically, it increases the metal’s tension and compression properties.
It was the first cost-efficient industrial process for the large-scale production of steel from molten pig iron, by taking out impurities from pig iron using an air blast.
Adding Carbon Produces a Variety of Iron Alloys
As previously mentioned, when mixed with carbon, the iron’s characteristics will be changed, allowing a variety of different types of metal alloys to be created. It all depends upon the amount of carbon that is added to it. Let’s take a look.
Wrought iron is softer than cast iron and contains less than 0.1 percent carbon and 1 or 2 percent slag.
It was an advancement over bronze and began to replace bronze in Asia Minor by the 2nd century BC. Because iron was far more plentiful as a natural resource, wrought iron was used for a wide variety of implements as well as weapons and armor.
Cast iron is an alloy of iron that contains 2 to 4 percent carbon, along with smaller amounts of other elements, such as silicon, manganese, and minor traces of sulfur and phosphorus. These minerals are nonmetallic and are referenced in the industry as slag. Cast iron can be easily molded into a desired shape, known as casting. and has been used to make decorative fences and other aesthetic forms.
Cast iron facades were invented in America in the mid-1800s and were produced quickly, requiring much less time and resources than stone or brick. They were also very efficient for decorative purposes, as the same molds were used for many buildings and a broken piece could be quickly remolded. Because iron is powerful, large windows were utilized, allowing a lot of light into buildings and high ceilings that required only columns for support.
The steel alloys mentioned above have carbon integrated within them, but stainless steel uses chromium as its alloying element. The result is that each produces a very different result when it comes to corrosion resistance. Stainless steel is much more corrosion-resistant.
Steel is an alloy made from iron that usually contains several tenths of a percent of carbon, which increases its strength and durability over the other forms of iron, especially in tensile strength.
Strictly speaking, steel is just another kind of iron alloy, but has much lower carbon than cast iron, and about as much carbon (or sometimes slightly more) than working iron, with other metals, frequently added to give it additional properties.
Most of the steel produced today is called carbon steel, or simple carbon, although it can contain metals other than iron and carbon, like silicon and manganese.
The advantages of steel are numerous, from great tensile and compression strength to the speed of manufacturing to low cost, it is the metal of choice in construction when compared to iron.
Although iron and steel appear to be similar, they are two distinct materials that have specific characteristics and qualities. Iron is a pure mineral and steel is an alloy material that contains a percentage of carbon. Depending on the amount of carbon mixed with iron, different products emerge, and this includes the creation of steel.
Steel is a far stronger material and there is no better metal at this time that is used when strength and cost are major factors.
The Lockheed SR-71 Blackbird is one of history’s most iconic spy planes. Also known as the “Black Widow” for its unique appearance, this aircraft still stands as an impressive feat of aeronautical engineering. It holds many speed and altitude records that have yet to be broken, and there is much more than meets the eye with this plane…
The Origins of the SR-71
Before this immortal aircraft was developed, the United States relied on the famous U2 spycraft for its Cold War reconnaissance. On May 1, 1960, a U2 was spotted deep inside Russian territory, but the US was not concerned as they believed that this aircraft was impenetrable to Soviet air defenses due to its high-altitude flight. They were wrong.
A Soviet V-750 surface-to-air missile shot down the spy plane. The pilot, Francis Gary Powers, who took off from a secret US airbase in Pakistan, parachuted to the ground safely but was immediately captured by Soviet authorities and taken prisoner.
He was later released after a mutual prisoner swap between the United States and Russia; however, it was quite clear that something else had to be done if the US wanted (and needed) to continue its reconnaissance over Russia and other foreign lands without the concern of the aircraft being shot down.
Corona Spy Satellite
The United States began an ambitious project for U2’s successor. The Corona spy satellite program was one of the first. It proved amazingly successful in August of 1960 after it was able to photograph many parts of Soviet territory.
What’s even more amazing was that the pictures that the plane took were sent back to earth and successfully salvaged, resulting in an abundance of intelligence well needed as this cold war intensified. The Corona program ended in 1972.
This prototype spawned some variants. The YF-12A Interceptor, which was designed to replace the F-106 Delta Dart Interceptor/ fighter, and the SR-71 Blackbird, was designed not as a fighter jet, but as a high-speed reconnaissance aircraft.
The YF-12A was built and tested but the Air Force decided to go for the F-111 fighter/bomber; however, the SR-71 was commissioned and 32 Blackbirds were eventually built.
The SR-71 was outfitted with all the advanced concepts from its A-12 parent, as well as the necessary devices (cameras and supporting equipment) for its intelligence mission to fly over foreign territory (namely the Soviet Union). This plane was able to fly much higher than the U2 and it flew four times faster. To this day, no aircraft has surpassed the speed of the SR-71 Blackbird.
Enter Skunk Works
This top-secret R&D group within Lockheed Corporation began during WWII to research advanced fighter aircraft, but its true meaning did not materialize until after the U2 was shot down.
As mentioned, it was evident that a more sophisticated aircraft that would be able to avoid Soviet planes and missiles, as well as being less vulnerable to radar signatures were required, or to put it another way, this new prototype had to be faster, higher, and stealthier than any other aircraft currently in existence at the time. The Skunk Works design team was tasked with creating this advanced aircraft.
Development of the SR-71
The design that Skunk Works had come up with was a radical break from conventional aircraft design. This plane would have a long, curved nose that would house a long-range camera and a shorter curved section behind that would house the pilot.
The idea behind this design was that it would significantly reduce the plane’s radar cross-section. Most of the aircraft’s volume would be behind the center of gravity, making the aircraft “lighter” from the perspective of radar. This would reduce the aircraft’s weight and make it fly even faster.
The plane would also be designed to minimize airflow, reducing drag and increasing speed. And all of this would be done with a plane that could carry almost 10,000 pounds of fuel and up to 10,000 pounds of payload.
Its futuristic profile made it difficult to detect on radar. Even the black paint used, full of radar-absorbing iron, helped hide its existence from the Russian radar defenses. Due to the plane’s unique design, some engineers viewed it as more of a spaceship than an aircraft.
The mineral titanium was one of the main reasons for the SR-71’s success. This metal is almost as strong as steel but lightweight enough not to allow the plane to fly and maneuver very well. Titanium is also able to withstand enormous temperatures when flying at 2,200 mph (3,540 kph).
And all this was done before digital functionality became commonplace.
Titanium and the Soviet Union
Even though titanium is the ninth most common element in the earth’s crust, its resources are lacking in the United States. And ironically, all the places where this mineral is abundant are in the Russian territories, so the United States created dummy companies to hide who was purchasing this needed mineral.
This aircraft was truly an extraordinary feat of engineering, and it had many specifications that would go on to set records and even become standards for future planes.
It had a crew of one and could fly at Mach 3.2 (2,455 MPH) at a height of 85,000 feet. That is almost halfway into the Earth’s stratosphere, and with a fuel capacity of 36,000 pounds, it could fly for over 2,500 miles without having to refuel.
Because it was designed to fly at very high altitudes, the SR-71 was pressurized, allowing the pilot to fly without a spacesuit. While flying at those altitudes, the plane would also be able to fly through weather that other aircraft could not fly in.
How Fast is the SR-71?
As mentioned this aircraft could fly at Mach 3.2. That’s faster than a bullet! Because the plane was streamlined, it was able to fly at those speeds without creating dangerously high pressures on the airframe. And this meant that the aircraft was able to maintain its altitude without using a lot of fuel to keep itself aloft.
This was a massive advantage for the SR-71, as it would let the aircraft fly for hours before needing to refuel. The speed record was set by retired Air Force colonel Bob Gilliland, who flew it from New York to London in 64 minutes, smashing the previous record. This equates to an average speed of 2,189 mph, which is still faster than any aircraft in service today.
Other Innovations by the Blackbird
As if breaking speed and altitude records weren’t impressive enough, the SR-71 also pioneered many other technologies that are still in use today. Here are some examples.
The SR-71 used a special fuel to cool itself, which is now used in many modern engines.
It had a special paint that didn’t reflect visible light or infrared light, making it incredibly stealthy.
The plane’s cockpit was also extremely advanced, with a heads-up display that projected critical information directly onto the windshield.
The navigation system was revolutionary, using Doppler beacons to accurately calculate the plane’s position.
The plane’s way of communicating with ground control stations was unlike anything used before. It had a special method of transmitting information as bursts of radio waves that could be received by a single ground station at a time. This was necessary because the aircraft had no way of knowing which ground station it was closest to.
The plane had a special method of using the airflow over the aircraft to cool its engines, which was necessary to prevent them from overheating at the plane’s high speeds.
The SR-71 Blackbird was one of the most advanced aircraft ever created. It pushed the boundaries of aeronautical engineering, and even in the modern digital age, it is still a very impressive machine.
This supersonic aeronautic advancement was extremely efficient and could travel long distances at supersonic speeds while carrying heavy payloads. It was also extremely stealthy, making it a difficult target to see and track.
Despite having been decommissioned in the 1990s, the SR-71 still holds much impressive speed and altitude records. It truly is one of the most impressive aircraft ever created and deserves its place as a legend in aviation history.
In the last few years, there has been a lot of buzz about the metal known as titanium. The reason is that it has quite a few properties that make it useful in everyday life.
It is strong, lightweight, and corrosion-resistant among other things. It is most popular for being used to create aircraft parts and car engine components; however, there is so much more to this metal than meets the eye.
People have used titanium for thousands of years. Only recently we have begun to understand exactly how useful this mineral can be. It was found to be extremely useful for military stealth functions, starting with the famous SR-71 reconnaissance aircraft, due to the metal’s strength and high-temperature resilience (as we will discuss below) and the fact that it is lightweight (e.g. in this case, functioning as a very strong material but light), it was perfect for this spy plane.
Let’s take a look at some interesting facts about titanium.
Properties Stronger than Steel
You might have heard that titanium is as strong as steel. While this is not entirely true, it is close enough to be significant. To begin with, strength is not a single chemical property of a material. But for simplicity, let’s treat it as one.
The tensile strength (measurement of a material’s elastic stress when a load is placed on it – how much it can withstand before starting to stretch or pull out before breaking apart) of steel is around 100 gigapascals (GPa) – the unit of measurement of tensile strength. (One pascal is equal to 1 newton of force per square meter).
The tensile strength of titanium is about 60 GPa. Therefore, steel is stronger than titanium. However, the thing to note here is that titanium’s strength is applied only at a very specific point. Let’s say that you have a piece of metal that has a high tensile strength across its entire surface. This does not make it stronger than a piece of metal with a lower tensile strength applied at a specific point.
Chemical Properties of Titanium
Titanium has a lot of unique properties that make it special. It has a very high melting point (more than 3,000 degrees Fahrenheit). Because titanium resists oxidation at high temperatures, it is often used in high-temperature applications.
Oxidation is the loss of electrons, resulting in the titanium atoms becoming vulnerable to combining with other atoms; subsequently changing their properties and compromising the material.
A perfect example of using titanium for its resistance to oxidization at high temperatures is that it makes an excellent material for the SR-71 since this plane could fly at Mach 2.5, which is close to 2,000 miles per hour. This metal is also corrosion-resistant. This means that titanium is very useful when exposed to water or air.
Titanium has an atomic number of 22 and an atomic weight of 47.867, which means it has 22 protons and approximately 48 protons and neutrons, respectively.
Everyday Uses of Titanium
Titanium is being used in many different industries, and there are several everyday uses of titanium that you may not be aware of. This is because titanium is lightweight, strong, and corrosion-resistant, making it the perfect material for sports equipment.
Sports equipment – If you are a sports fan, you may have seen athletes wearing titanium-containing sports accessories.
Medical equipment – If you ever get an MRI scan, you may be inside a machine that is made of titanium. This is because titanium is very safe to use around living tissue and can be sterilized easily.
Marine parts – If you own a boat, you may be surprised to learn that the propellers and rudders are often made of titanium. This is because it is strong, lightweight, corrosion-resistant, and does not affect water flow.
Water and air purification – You may have seen pictures of large towers in cities. These towers are used for water purification and are often made of titanium.
Construction – Buildings, bridges, and other infrastructure are often constructed using titanium. This is because it is highly corrosion-resistant and very strong.
Food packaging – If you have ever eaten food that was in a pouch, there is a good chance that the pouch was made of titanium.
How is Titanium Produced?
Titanium is made through a process known as the Kroll process. – First, titanium ore is mined and then sent to a smelter where it is heated to extremely high temperatures.
The resulting molten metal is then sent through a chemical reduction process which removes oxygen and other impurities. The molten metal is then cast into ingots and then rolled into long bars. These bars are then drawn through a press that elongates them and makes them thinner. Finally, the bars are shaped into their final forms and then sent to be coated or processed further.
Problems with Manufacturing and Existing Processes
As you have read, titanium is a very versatile material that can be used in a wide variety of industries. However, there are some issues with the current methods of manufacturing this mineral that needs to be addressed.
High costs – Currently, the process of producing titanium is very energy-intensive and expensive. The cost of the metal itself is also quite high, making it costly to produce certain products.
Contamination – The process of manufacturing titanium is quite complex, and there is a risk of contamination in certain areas of the process.
High purity requirements – Another issue with titanium is that it has very high purity requirements. This means that the resulting metal can be very impure even after the purification process.
Difficult to produce large quantities of titanium in the quantities needed for the industries that use it.
Titanium is a very versatile metal that can be used in a wide variety of industries. However, due to its high costs and difficult manufacturing process, it is often difficult to produce large quantities of titanium. With that said, titanium is used for very specific functions. This article has explored the many uses of titanium and the process behind its manufacture.
In the 19th century, with the advent of structural steel, engineers began using cantilevers to construct taller buildings. This type of architecture is primarily used when there isn’t enough space on one side of a structure for its foundation. Engineers have to build the foundation out from one side and then use beams that extended from it to support the weight.
This construction style is eye-catching and certainly more daring than other methods of building. It also requires serious engineering skills, as well as a detailed understanding of how much weight the beams can bear without giving way. Indeed, the correct structural engineering is imperative as just a small miscalculation in the production of steel and concrete can result in catastrophe.
If you live in a big city, you might have noticed that more buildings are being built with these overhangs. This is especially true for cities where space is at a premium, such as New York City. In this article, we are going to take office building construction to a whole new level – the use of cantilevers!
The Citicorp Center, New York City
If there was ever a building that emphasised cantilever design it would be the Citicorp Center in midtown Manhattan. Completed in 1977, the 59-story, 915-foot-high skyscraper sits on three stilts with an internal core at the center.
The building is structurally sound now; however, thanks to an observant doctoral student at Princeton University, a discrepancy was discovered when wind forces hit particular angles of the building.
In 1978, Diane Hartley, who was writing a structural engineering thesis, found that the engineer’s calculations did not match hers, which was disturbing since it indicated a possibly dangerous situation.
Should a strong windhappen to hit the building’s corners, the possibility of the building toppling over had a chance of collapse. It was a one-in-16 chance, but the danger still existed.
Hartly proceeded to notify William LeMessurier, who was the chief structural engineer. He checked her math and realized she was correct.
Quietly, LeMessurier proceeded to correct the issue. In coordination with the NYPD, an evacuation plan was enacted, which covered a ten-block radius. An evacuation almost materialized as a hurricane was forecast to be heading towards NYC. Hurricane Ella was on its way but moved away from the city at the eleventh hour.
Interestingly enough, word did not get out about this until 1995 when it was published in the New Yorker Magazine.
In addition to the skyscraper’s unusual cantilevered design, the developers used their ingenuity to build a large solar panel at the top of the structure; hence, the slanted roof at the top points south. But the idea never materialized, the slanted roof remains as an esthetic addition to the building.
The Rotterdam Tower
This intriguing building is located in the Netherlands and is part of the Erasmus Bridge Complex. It is a mixed-use building that houses offices, a hotel, and apartments. The building has a cantilever design, which is why the residents can enjoy a gorgeous view of the river
The architects designed the building so that it extends out over the river and almost touches the bridge. They also designed it so that it is taller on one side. The weight of this building is distributed between its central core and its cantilever, which is why it can be so tall without the ground beneath it being affected.
Statoil Regional and International Offices
Statoil is an energy producer in Norway and the 57th largest company in the world. Norwegian architects A-Lab designed a 117,000-square-meter commercial building complex that fits into the picturesque shoreline of Fornebu in perfect harmony.
Additionally, this architectural expression injects new energy into the nearby park and commercial area and was a key challenge in their design. Of course, it is the overhangs that make the building stand out. They stretch up to 100 feet in many directions.
Marina Bay Sands Hotel
The Marina Bay Sands Hotel is considered one of the most impressive hotels in the world. It is a massive construction project that began in 2003 and was completed in 2011. The project was a collaboration between the Las Vegas Sands Corporation and the Singapore government and was built on the site of a former shipyard. The hotel has three 55-story towers. but in addition to these buildings, it has a sky park that is cantilevered over all three towers.
Designed by Israeli architect Moshe Safdie, the hotel has 2,500 rooms and a lobby that crosses the entire three buildings just like the sky park above.
One of the most interesting aspects of the construction of the hotel was that developers used an unusual design that allowed them to build upwards while keeping the foundations stable.
This was necessary because Singapore is located on a floodplain, and it is impossible to build foundations below ground level, so the engineers designed the foundation so that the bottom of the hotel would be constructed on a metal mesh, which would be anchored to the ground. The mesh would keep the foundation stable while allowing sand and water to flow freely through it. The foundation is built in modular sections, which can be raised and lowered as necessary. The builders also used a system of shuttles to transport construction materials to the upper floors of the hotel, as well as the rooftop.
Lessons Learned from MBS’s Construction
As we have seen, the construction of the Marina Bay Sands Hotel was a challenge. It is rare for the ground to shift so dramatically in an area where there is no flooding, and it is even more unusual for builders to build on top of a metal foundation. Although this construction project was unique, it still provides some important lessons for other builders.
The first is that challenges are an inevitable part of construction, and there are always several factors that have to be taken into account. The second is that challenges should not be seen as a reason to abandon the project. When building on the water, the builders of the Marina Bay Sands had to be flexible, and ready to make adjustments at any time. If they had been too rigid, they may not have been able to proceed with the project at all.
One Vanderbilt – New York City
With space so much at a premium in this city, the only way to build is up, and even then, it might not be enough to encompass the amount of office space that the developers envisioned for the Vanderbilt tower.
Located across from Grand Central Terminal, it is the fourth tallest building in NYC, rising 1,401 feet above the ground. On the south and west sides, it is cantilevered over Vanderbilt Ave. and 42nd Street respectively, and this overhang starts at only approximately 50 feet up and then supports the rest of the superstructure. There is an observatory at the top, which is the 5th observatory in Manhattan.
Other skyscrapers with noticeable cantilevered construction in New York include Central Park Tower and the Citicorp Headquarters, displayed above.
J. P. Morgan Chase Headquarters – New York City
Also known as 270 Park Ave., this 1,388-foot-tall, 70-story, 2.5 million-square-foot super tower is located between Park and Madison Avenues, and 47th and 48th Streets.
This massive building will be supported, in part by steel cantilever columns that protrude diagonally out on the eastern and western sides of the building.
Interestingly, the building is replacing the former Union Carbide 52- story tower (later bought by Chase) that was previously there. The building was completely demolished, which made it the largest intentionally demolished building in the world.
No doubt, this will be one of New York’s most advanced skyscrapers.
Frank Gehry’s Chiat/Day Building
This building is a former office building in Los Angeles, California that was converted into a mixed-use building. It is now home to a variety of businesses, as well as the famous advertising agency Chiat/Day.
Designed by notable architect Frank Gehry, this building with a cantilever on one side so that it could house all of the businesses. They designed the cantilever so that it wouldn’t cause damage to the building’s foundations.
The building’s cantilever also allowed designers to create an interesting façade. They were able to extend the second floor out so that it creates a terrace, which is accessible from the sidewalk.
The cantilever is an interesting architectural feature that many people likely do not think about as they walk under these overhangs, but it is a complex engineering solution that isn’t suitable for every project; however, in these examples, it works brilliantly.
While they may be pretty to look at, they also serve a critical function, which makes them a necessity. While the specific structural design of each cantilever will vary depending on the building type, design, and geographic location, the overall concept is the same.
By far, the most extraordinary images from outer space that have ever been received have come from the James Webb telescope. As the successor to the famous Hubble Space Telescope, the James Webb is the most powerful space observatory ever built, with far more potential than anything that has come before it.
Launched on Christmas Day, 2021 on the Ariane 5 rocket, this giant observatory, the size of a tennis court, is currently in L2 Orbit, located 1.5 million miles from Earth, sending extraordinary images of objects from as back into time as when the big bang started -13.7 years ago.
To understand why this matters so much to humanity, we first have to understand what the JWST is not. It is not a souped-up version of the Hubble; nor is it an alternative to Hubble — something different but still essentially the same.
Instead, the JWST represents a completely new paradigm in design and function for a space-based optical telescope. In other words: It’s like nothing we’ve ever seen before.
How Does the JWST Differ from Hubble?
The two telescopes, while both space-based observatories are very different in two significant categories.
Size Does Matter!
There is a major difference between the JWST mirrors and the Hubble’s mirrors in size. As discussed further in the article, the bigger the mirror, the further back into space we can see.
As a result, this amazing observatory is also about 10 times more powerful than Hubble, with a much wider field of view — and, therefore, able to observe more objects.
This is significant because only a very small percentage of the universe’s atoms emit visible light, while almost all atoms emit infrared light. As such, the JWST — in conjunction with other telescopes that are observed in other wavelengths allows us to view a much bigger chunk of the universe than Hubble ever could.
In addition to infrared, the JWST also has a small segment that observes a type of ultraviolet light that is inaccessible to Hubble.
Why is the JWST Important?
The JWST is a completely different kind of telescope that exploits a different approach to astronomy and will, therefore, produce many different results.
With its ability to detect light from the first stars that ever formed in the universe and the first galaxies that ever formed after the Big Bang, it will, for the first time, give us a comprehensive picture of the evolution of the cosmos.
The JWST will also allow us to look for the earliest signs of life beyond our planet and, as such, represents a major step on humanity’s path toward enlightenment, as well as a greater understanding of who, what, and where we are.
The Telescope Assembly
The observatory is primarily composed of three components:
This is where the mirrors are contained. The mirrors are the most significant part of the telescope. Simply put, the larger the mirror, the further back in space we can see and with greater detail, More specifically, the size of the mirror is directly proportional to the sensitivity (detail) that the telescope can display. The larger it is, the more detail it will show.
This amazing high-tech instrument consists of hexagonal-shaped mirror segments that measure over 4.2 feet across and weighs approximately 88 pounds. It has 18 primary segments that work in symmetry together to produce one large 21.3-foot mirror.
The mirrors are made of ultra-lightweight beryllium, which was chosen due to their thermal and mechanical properties at cryogenic (low) temperatures, as well as beryllium’s weight which made it a lot easier to lift it into space.
“The James Webb Space Telescope will be the premier astronomical observatory of the next decade,” said John Grunsfeld, astronaut and associate administrator of the Science Mission Directorate at NASA Headquarters in Washington. “This first-mirror installation milestone symbolizes all the new and specialized technology that was developed to enable the observatory to study the first stars and galaxies, examine the formation of stellar systems and planetary formation, provide answers to the evolution of our solar system, and make the next big steps in the search for life beyond Earth on exoplanets.”
Amazingly, the mirrors will fold to fit into the spacecraft and then unfold when ejected into outer space.
“After a tremendous amount of work by an incredibly dedicated team across the country, it is very exciting to start the primary mirror segment installation process,” said Lee Feinberg, James Webb Space Telescope optical telescope element manager at Goddard. “This starts the final assembly phase of the telescope.”
Bill Ochs, James Webb Space Telescope project manager said “There have many significant achievements for Webb over the past year, but the installation of the first flight mirror is special. This installation not only represents another step towards the magnificent discoveries to come from Webb but also the culmination of many years of effort by an outstanding dedicated team of engineers and scientists.”
The Spacecraft Element
Something must power this system and the spacecraft element is what does it. It supplies the rocket thrusters, propulsion system, communications, and all the electrical power needed to make this run as awell-oiledd machine.
Where are We Now?
We will leave you with this. Galaxy cluster SMACS 0723, which contains thousands of galaxies is 4.6 billion light years away.
That means that we are looking at it the way it looked 4.6 billion years ago. Scientists have a lot of work ahead of them and who knows what they’ll find?
